| 1 | Body Size | 1-1/4" |
|---|---|---|
| 2 | Burst Pressure | 4000 PSI (275 bar) |
| 3 | Factory Part Number | V10F10-B-E |
| 4 | Hex | 1-7/8" |
| 5 | Length | 2.22" (56.4mm) |
| 6 | Material | Brass |
| 7 | Maximum OD | 2.06" (52.3mm) |
| 8 | Maximum Operating Pressure | 1000 PSI (70 bar) |
| 9 | Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| 10 | Thread | Female NPTF |
| 11 | Thread Size | 1-1/4" - 11-1/2 |
| 12 | Weight Lb | 0.5600 |
