| 1 | Component Material | Ball: nickel-plated |
|---|---|---|
| 2 | Description | High pressure ball valve |
| 3 | Female Thread | ORB |
| 4 | Female Thread Size | 1-5/8"-12 |
| 5 | Finish | Zinc clear coating |
| 6 | Material | Carbon steel |
| 7 | Maximum Temperature | 215°F |
| 8 | Minimum Temperature | -20°F |
| 9 | Factory Part Number | HPBV125SAEZPL |
| 10 | Seal | Buna-N O-rings |
| 11 | Seat | POM (Polyacetal) ball seats |
| 12 | Size | 1-1/4" |
| 13 | Working Pressure | 6000 PSI |
