SKU :  9386 BRAND : DIXON VALVE MODEL :  BSVD-SC250B025

Applications:
The BSV-Series sample valve allows easy and safe sampling of liquids from closed systems such as vessels and pipelines.
These valves are located in the pharmaceutical, bio-pharmaceutical, biochemical, cosmetic, food, dairy and beverage markets.

Specifications:
Maximum pressure: 116 PSI
Actuator control air pressure: 87-145 PSI
Maximum temperature: 250°F (121°C)
Maximum cleaning temperature: 275°F (135°C) for 20 minutes

Features:
Valve body made from solid bar
No dead space
Drainable
Connections suitable for orbital welding
Available with single or dual ports
Hermetically sealed against environment
Optimum cleanability
Change of seals without special tools
Long life of the PTFE-bellows
Low spare part costs

Construction:
Product contact metal: 316L stainless steel, ≤ 32Ra surface finish
Non-product contact metal: 304 stainless steel, ≤ 63Ra surface finish
Product contact seals: PTFE Bellows

Available Options:
Different surface finishes
Various connection types

Safety notes:
WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov
