| 1 | Body Size | 1" |
|---|---|---|
| 2 | Burst Pressure | 13500 PSI (900 Bar) |
| 3 | Factory Part Number | AG8F8 |
| 4 | Hex | 1-5/8" |
| 5 | Length | 2.57" (65.3mm) |
| 6 | Material | Steel |
| 7 | Maximum OD | 1.76" (44.7mm) |
| 8 | Maximum Operating Pressure | 3000 PSI (200 Bar) |
| 9 | Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| 10 | Thread | Female NPTF |
| 11 | Thread Size | 1" - 11-1/2 |
| 12 | Weight Lb | 0.6100 |
