| 1 | Body Size | 1/4" |
|---|---|---|
| 2 | Burst Pressure | 24400 PSI (1700 Bar) |
| 3 | Factory Part Number | AG2F2 |
| 4 | Hex | 3/4" |
| 5 | Length | 1.42" (36.0mm) |
| 6 | Material | Steel |
| 7 | Maximum OD | 0.84" (21.3mm) |
| 8 | Maximum Operating Pressure | 4000 PSI (275 Bar) |
| 9 | Temperature Range | -40°F to +250°F (-40°C to +121°C) |
| 10 | Thread | Female NPTF |
| 11 | Thread Size | 1/4"-18 |
| 12 | Weight Lb | 0.0900 |
