DIXON VALVE 2AGF2 AG-Series Agricultural Ball Valve Female Threaded Coupler
* Referential image

DIXON VALVE
AG-SERIES AGRICULTURAL BALL VALVE FEMALE THREADED COUPLER
SKU :  3003 BRAND : DIXON VALVE MODEL :  2AGF2
Applications:
Used on construction equipment, farm implements and most other mobile equipment

Specifications:
The International Standard Organization (ISO) has adopted specifications regarding dimensions and interchangeability.

Construction:
Machined components are manufactured using solid bar stock
Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life.
Steel componentry is plated using ROHS Compliant Trivalent Chrome.
Steel coupler sleeves are hardened to resist deformation and maximize service life.
Nitrile (Buna-N) seals are standard
Couplers have a PTFE Anti-Extrusion ring
Ball valve and poppet valve options available

Compatibility & Interchange Data:
Pioneer Agricultural Interchange
Parker/Pioneer 4000 Series
Safeway S20

Safety notes:
WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov
PDF
TECHNICAL SPECIFICATIONS
1Body Size1/4"
2Burst Pressure24400 PSI (1700 Bar)
3Factory Part Number2AGF2
4Hex7/8"
5Length2.06" (52.32mm)
6MaterialSteel
7Maximum OD1.12" (28.45mm)
8Maximum Operating Pressure4000 PSI (275 Bar)
9SealBuna-N
10Temperature Range-40°F to +250°F (-40°C to +121°C)
11ThreadFemale NPTF
12Thread Size1/4"-18
13Weight Lb0.2800
** Some features may vary without prior notice. Sale subject to inventory availability
