DIXON VALVE
DIXON VALVE 1HF1-B DQC H-Series ISO-B Poppet Valve Female Threaded Coupler
* Referential image

DIXON VALVE
DQC H-SERIES ISO-B POPPET VALVE FEMALE THREADED COUPLER
SKU :  22218 BRAND : DIXON VALVE MODEL :  1HF1-B
Features:
Poppet style shut-off valves

Construction:
Machined components are manufactured using solid bar stock
Stainless steel balls, retaining rings and springs maximize corrosion resistance and extend service life.
Steel componentry is plated using ROHS Compliant Trivalent Chrome.
Steel coupler sleeves are hardened to resist deformation and maximize service life.
Nitrile (Buna-N) seals are standard
Has a redundant O-ring sealing system (dual O-Rings/no PTFE back-up ring_

Available Options:
Contact Dixon for all available option adders
Standard seal options include: FKM, EPDM, Steam-EP, FDA FKM, Mil-Nitrile, Fuel Nitrile, PTFE and Silicone
Kalrez® seal options include: 4079, 6375 and 7075
Valve options include: Unvalved, actuator, steel, brass, 303 stainless steel and 316 stainless steel
Sleeve options include: Sleeve-lock, Flanged and Silicone-flanged
Oxy-clean treatment is available

Compatibility & Interchange Data:
Meets dimensional requirements of ISO 7241 Series B
Interchangeable with Parker-Hannifin 60 Series, Snap-Tite 72-Series, Hansen HK-Series, Faster Series 'HNV', Aeroquip/Eaton FD45, Stucchi Series IRB/IRBO/IRBX

Safety notes:
WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov
PDF
TECHNICAL SPECIFICATIONS
1Body Size1/8"
2Burst Pressure16500 PSI (450 bar)
3Factory Part Number1HF1-B
4Hex9/16"
5Length1.90"
6MaterialBrass
7Maximum OD0.93"
8Maximum Operating Pressure3000 PSI (200 bar)
9Temperature Range-40°F to +250°F (-40°C to +121°C)
10ThreadFemale NPTF
11Thread Size1/8"-27
12Weight Lb0.1600
** Some features may vary without prior notice. Sale subject to inventory availability
